Air conditioning Problems



Leaks / Low Refrigerant

No vehicle A/C system is completely, 100% sealed.  Over the years, small refrigerant particles will leak out mainly on rubber components up to 15% per year.  On smaller-capacity systems this will become noticeable a lot quicker than larger capacity systems.

Symptoms of low refrigerant include rapid cycling of the compressor clutch, or clutch will not engage, little or no cooling, very oily spots on A/C components.

A severe leak will require repair or component replacement.  To find a leak we would do a Nitrogen Pressure test this is the most effective ways of finding a leak.

Once the leak is identified, the component should be repaired or replaced, and the system serviced.

Restrictions

A restriction is a condition where some piece of debris has lodged in a component, and is 'restricting' the flow of refrigerant.  Condenser restrictions are the most common.  Most late-model condensers have very small passages, as low as 6mm.  When there is a restriction in the system, the flow of refrigerant is greatly reduced, or sometimes stopped completely.  The blockage causes pressure to build up behind the restriction, and will cause damage to the components behind it.

Some restrictions can be repaired by flushing the restricted component, but parallel-flow condensers usually need to be replaced.

Also some restrictions can be caused by a bad rush job air-con re-gas as moisture is not removed and causes internal icing up this can often happen when you have just a top up or use a can kit.

Improper Refrigerant Charge

As A/C systems become smaller and smaller, the amount of refrigerant in the system becomes critical.  The correct charge for an A/C system has been calculated and engineered by vehicle manufacturers for optimum performance.

Too much!  Your A/C isn't quite cooling, so you run down to a shop, and buy a recharge can kit.  We in the industry call them A/C Killers.  You add a can of refrigerant.  Well, with A/C, too much isn't better.

tip:

If your system is working and sealed, you DO NOT need to replace your filter drier or accumulator.  This is not a part that wears out.  The only time you need to replace it is when the system is opened, or if you've had a leak that allows air (and moisture) into the system.  If someone tells you you need to replace it every 3, 5 or 7 years, they're trying to sell you something.



Bad Smell

This is a fairly common complaint. What causes it?

It is principally caused by the growth of bacteria on the AC evaporator and in the remains of any water (condensate) still sitting in the plastic box that surrounds the evaporator. In a mild case it smells similar to a fridge which is opened for the first time after several days. In a serious case it can smell a great deal stronger and was once described to me as being like 'cat's wee'. We all have different abilities in our sense of smell and what may be a slight annoyance to one person might be almost unbearable to another.

Firstly let me reassure you that contrary to what you may have heard elsewhere it is not possible to contract Legionnaires Disease from the AC in a car. Legion Ella Pneumophila are a problem only in the air conditioning systems of large buildings where they use chilled water to transmit the cooling from one part of the building to another. No vehicle uses any water to achieve the cooling.

Nevertheless it may be possible to contract slight throat infections from a poorly maintained car AC system. I haven't yet seen any definitive proof that this is possible but over the years a number of people I have spoken to are convinced that this has happened to them. In fact during 2015 I heard of one case of pneumonia that almost certainly was of an airborne bacteria which had probably somehow entered the evaporator and caused a very serious disease in one individual which might have even proved fatal. Although not proved to have been transmitted via the AC as it is airborne, that route was thought by the consultant to have been very likely.

How do these bacteria appear in sufficient numbers to cause either a smell or a health problem? If the car's AC is working well then new condensate is appearing on the evaporator all the time and simply washes any existing bacteria off, collects in the tray beneath and then drips onto the road through the condensate pipe. But if the AC is scarcely working, usually due to low refrigerant charge, this condensate is not being produced and this small amount of water becomes polluted with bacteria, verdigris and every other nastiness there may be in the air and with fairly ideal breeding conditions in a warm damp place turns into a veritable soup which will probably pong to high heaven. Quite simply recharging the AC and bringing the condensate supply back to normal may wash this nastiness away and within a day or so may completely remove the unpleasant smells. Sometimes however perhaps due to the design of the evaporator the smell lingers a little. Rather than trying to disguise it with scented products it is better to eliminate it altogether with a bacterial disinfectant in the form of an aerosol spray or better still an ultrasonically produced disinfecting mist which is circulated around the cabin, the vents, the ducting and the evaporator.

How to rid your car of these bacteria? Often simply recharging the system will cure the problem. If however the car has been recharged recently and yet the smell still persists then the problem is likely to be more deep seated and the system airways may need disinfecting. The cheap and easy method is to buy a specialist aerosol from a motor factor or accessory shop which will disinfect and deodorize the evaporator, just follow the instructions on the can. Perhaps the best method for stubborn cases is the fine mist deodorizer produced by an ultrasonic piezo device. This bit of kit is too expensive for the average car owner to consider owning but cleaning using this or similar equipment is often offered as a service by AC professionals
